| 产品规格 | AI边缘算力盒子 TS-NV-P300(16GB/8GB) | AI边缘算力盒子 TS-NV-P300X(8GB/4GB) | AI边缘算力盒子 TS-NV-P300S(16GB/8GB) | |
| 操作系统 | SoC | NVIDIA Xavier NX | NVIDIA ORIN NANO | NVIDIA ORIN NX |
| CPU | 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU | 6核Arm®Cortex®-A78AE v8.2 64CPU；1.5GHZ | 16GB：8核ARM Cortex A78AE V8.2 64位 8GB：6核ARM Cortex A78AE V8.2 64位 | |
| GPU | 384-core NVIDIA Volta™ GPU with 48 Tensor Cores | 8GB：1024*CUDA核心和32个Tensor Core Ampere架构 4GB：512*CUDA核心和16个Tensor Core Ampere架构 | 1024*CUDA核心和 32个Tensor Core Ampere架构 | |
| 内存 | 8GB or 16GB LPDDR4x 59.7GB/S | 8GB 128位LPDDR5 68 GB/s;4GB 64-bit LPDDR5 34GB/S | 16/8GB 128位LPDDR5 102.4GB/S | |
| eMMC | 16GB eMMC 5.1 | 支持外部NVME | 支持外部NVME | |
| Computing Power | INT8：21Tops；FP16 | 8GB：40TOPS(INT8)；4GB：20TOPS(INT8) | 16GB：100TOPS(INT8)；8GB：70TOPS(INT8) | |
| 视频 | 编码 | 20*1080P30(H.264)|4*4K P30 | 4*1080P30 | 1*4k60(H.265)|14*1080P30(H.265) |
| 解码 | 22*1080P30(H.264)|12*4K P30 | 1*4K60(H.265)/2*4K30(H.265)/11*1080P30(H.265) | 24*1080p30(H.265)|6*4k 30(H.265) | |
| HDMI | 1 x HDMI 2.0 | |||
| LAN | RJ45 | 1*100M/1000M M12 or RJ45，4*POE RJ45 100M/1000M | ||
| USB | USB | 2* USB3.0；2*USB2.0；1*USB TypeC debug | ||
| I/O (凤凰端子 Plug) | RS485 | 1*，D+ and D-，connector with DB9 | ||
| DI/DO | 6-bit(3IN-3OUT)GPIO，2*GND，connector with 凤凰端⼦ | |||
| RS232 | 1*，RXD and TXD，connector with DB9 | |||
| CAN | 2*CAN with 凤凰端⼦ | |||
| Expand | Expand | M.2 nvme SSD（Upper 2TB）；1* NANO SIM,1* Micro SD；1* 4G/5G，1*GPS，1*Wi-Fi | ||
| Audio | Audio | In/Out 3.5mm Earphone holder | ||
| Key | Key | Recovery*1；Reset*1 | ||
| Power | Conn | aviation plug，4Pin；DC 9 ~ 36V (Typical：DC12V 5A)，支持车载ECC制 | ||
| 指示器 | Power/run | Power indicator (green power on，NO light power off)；System operation indication | ||
| 4G/HDD | 4G signal indication (green, resident network on, search network flashing, offline off) | |||
| 尺寸 | 192.0*183.0*81.0mm(无天线)，3KG | |||
| 环境 | Operational Temperature：-20℃—70℃；Storage Temperature：-40℃—80℃ | |||
