TS-SG-SM7 Series

The Tensortec AI Computing Module TS-SG-SM7 is powered by Sophgo’s AI chip BM1684X and supports multimodal large models. It can be integrated into edge computing boxes, smart NVRs, robots, drones, and more, efficiently adapting to various scenario-specific AI algorithms. This enables the implementation of applications such as facial recognition, video structured analysis, behavior analysis, and condition monitoring, providing AI empowerment for industries including wisdom‑enabled cities, power systems, transportation, and coal mines.

Manual download Contact us

Product Highlights

01

Ultra-high computing power, super strong decoding

32TOPS INT8 computing power, 8-core A53 flexible application development
32-channel 1080P video decoding and 12-channel 1080P video encoding
02

Wide temperature range and low power consumption, flexible deployment

With a wide temperature range of -40℃ to +70℃, it can flexibly adapt to different environments
Two-thirds the size of a credit card, with a typical power consumption of less than 18W
03

Dual-mode drive, strong scalability

The PCIE Mode can be used as a slave device, and the SoC Mode as the master device
The interface is rich and the function expansion is convenient

Application Scenarios

AI Server
Edge Computing Box
Robot
Drone

Intelligent NVR
Edge Gateway
AIoT Terminal
Intelligent Container

Product Specifications

Product Name	AI Computing power Module
Product Model	TS-SG-SM7 Series
Processor	8 Cores ARM A53@2.3GHz
AI Computing Power	INT8	32TOPS
	FP16/BF16	16TFLOPS
	FP32	2TFLOPS
Video/Image Encoding and decoding	Video Decoding Capability	H.264&H.265:32 channels 1080P@25fps; The maximum resolution supports 7680 x 4320
	Video Coding Capability	H.264&H.265:12 channels 1080P@25fps; The maximum resolution supports 7680 x 4320
	Image decoding capability (JPEG)	400 frames per second @1080P The maximum resolution supports 32768 x 32768
Memory	Standard configuration	16GB
eMMC	Standard configuration	64GB
Interface	PCIE	PCIE 3.0 x 4 EP + x 4 RC
	Network interface	10/100/1000Mbps RGMII x 2
	Bus interface	GPIO/SDIO/PWM/I2C, etc
Connector	Interface specification	144-PIN BTB Connector
Working temperature	Temperature range	-40℃ ~ +70℃ (Non-cold start)
Power consumption	Typical value	30W
Size	Length * width * height	62.0 x 58.0 x 33.45mm
