TS-NV-P200 Series

With 5G+AI serving as the engine of digital economic growth, the penetration of AI empowerment continues to expand. AI edge computing, leveraging its strengths in low latency, stability, reliability, and flexible scalability—combined with cloud-edge integrated application systems—has emerged as a key trend in data‑driven intelligence.

The Tensortec TS‑NV‑P200 series AI Edge Computing Box is an edge computing product developed based on the NVIDIA Jetson Xavier NX/Orin NX/Orin Nano embedded ARM architecture and powerful SoC chips. It provides a mature, comprehensive, and reliable AI hardware and software development environment along with full‑cycle support services, enabling straightforward algorithm migration and streamlined product engineering. This significantly shortens the time‑to‑market for AI solutions. Built with industrial‑grade design, the product ensures stable and reliable operation.

Product Highlights
  • 01
    The algorithm transplantation cycle is short

    Nvidia jeston jetpack Standard Development Kit: Ubuntu Linux OS CUDA cuDNN OpenCV tensorRT etc, support Caffe TensorFlow/Pytorch Mxnet/Paddle Lite degree of mainstream learning framework, etc.

  • 02
    Ultra-high-performance AI computing and codec capabilities

    The GPU has strong comprehensive computing power and is equipped with the latest NVIDIA AI engine TensorRT.

  • 03
    Rich interfaces and flexible deployment capabilities, AIoT edge integration
    USB, HDMI, RS-485, RS232, RJ45, custom I/O, etc.
  • 04
    Dual Gigabit Network Cards
    Supports high-precision Beidou +GPS; Supports extended Wi-Fi, 4G/5G.
  • 05
    Supports Overall Expansion
    Supports M.2 NVMe SSD overall disk expansion.
  • 06
    Vehicle-specific products, stable and reliable
    Condensing silicone grease has excellent heat dissipation performance, a wide operating temperature range, and supports aviation plug-in power supplies.
Application Scenarios
  • Industrial Machine Vision
    Industrial vision inspection, etc
  • Intelligent Transportation
    Holographic intersections, vehicle-road coordination, etc.
  • Smart Vehicle
    Road maintenance, smart patrol, unmanned vehicles, intelligent education and training vehicles, etc
Product Specifications
Product Specification

AI Edge Computing Power Box

TS-NV-P200 (16GB/8GB)

AI Edge Computing Power Box

TS-NV-P200X (8GB/4GB)

AI Edge Computing Power Box

TS-NV-P200S (16GB/8GB)

Operating System SoC NVIDIA Xavier NX NVIDIA ORIN NANO NVIDIA ORIN NX
CPU 6-Core NVIDIA Carmel ARM®v8.2 64-bit CPU 6 Cores Arm®Cortex®-A78AE v8.2 64CPU;1.5GHZ 16GB:8 Cores ARM Cortex A78AE V8.2 64
8GB:6 Cores ARM Cortex A78AE V8.2 64
GPU 384-core NVIDIA Volta™ GPU with 48 Tensor Cores 8GB:1024*CUDA cores and 32 Tensor cores Ampere architecture
4GB:512*CUDA cores and 16 Tensor cores Ampere architecture
1024*CUDA cores and 32 Tensor Core Ampere architecture
Memory 8GB or 16GB LPDDR4X 59.7GB/S 8GB 128 位 LPDDR5 68GB/s;4GB 64-bit LPDDR5 34GB/s 16/8GB 128 位 LPDDR5 102.4GB/s
eMMC 16GB eMMC 5.1 Supports external NVME Supports external NVME
OS Ubuntu 18.04; CUDA 10.2; Jetpack 4.5.1----Jetpack 4.6.3; Or Ubuntu 20.04, jetpack5.1.1
Computing Power Computing Power INT8:2.1Tops;FP16 8GB:40TOPS(INT8); 4GB:20TOPS(INT8) 16GB:100TOPS(INT8); 8GB:70TOPS(INT8)
Video Coding 20*1080P30(H.264)|4*4K P30 4*1080P30 1*4k60(H.265)|14*1080P30(H.265)
Decoding 22*1080P30(H.264)|12*4K P30 1*4K60(H.265)/2*4K30(H.265)/11*1080P30(H.265) 24*1080p30(H.265)|6*4k 30(H.265)
HDMI 1 x HDMI 2.0
LAN RJ45 4*RJ45 100M/1000M
USB USB 2USB3.0;2USB2.0; 1*USB TypeC debug
I/O (Phoenix Terminal Plug) RS485 1*RS485-A, RS485-B, GND
DI/DO 6-bit (3IN-3OUT) GPIO, 2*GND, connector with Phoenix Terminal
RS232 1*RS232 RX, RS232TX, GND
CAN 1*CAN with Phoenix Terminal
Expand Expand M.2 nvme SSD(Upper 2TB);1* NANO SIM,1Micro SD;14G/5G,1北斗 + GPS,1Wi-Fi
Audio Audio In/Out 3.5mm Earphone holder
Key Key Recovery1;Reset1
Power Conn aviation plug, 4Pin; DC 12V 5A
Indicator Power/run Power/run Power indicator (green power on,NO light power off);System operation indication
4G/HDD 4G signal indication (green, resident network on, search network flashing, offline off)
Size 125*118*55  (No antenna, no USB fixed bracket, no power source. The length with the power source is 145mm and the width with the USB fixed bracket is 148mm.) Weight: 1kg
Environment Operational Temperature:-20℃~65℃;Storage Temperature:-40℃~85℃
