TS-RK-F200B Series

With 5G+AI+IoT serving as the engine for the development of the digital-intelligent economy, AIoT empowerment and penetration are becoming increasingly widespread. AI Edge Computing Boxes, leveraging advantages such as low latency, high security, and extensive connectivity, combined with a cloud-edge integrated application system, are more conducive to effective data perception and digital-intelligent upgrades. The Tensortec TS-RK-F200 Series AI Edge Computing Box is designed and developed based on the domestic Rockchip RK3588 platform, featuring an advanced embedded ARM architecture and a high-performance SoC chip. It provides a mature, comprehensive, stable, and reliable AIoT hardware and software development environment with supporting services, simplifying algorithm porting, facilitating IoT connectivity, and easing product engineering development. This significantly shortens the deployment cycle of AIoT products, all within an industrial-grade design that ensures stability and reliability.

Product Highlights
  • 01
    Professional AI edge computing power box
    Combining AI, IoT, connectivity, high security, etc.
  • 02
    Full-stack system capability
    Ubuntu Linux/ Debian/ Android。
  • 03
    Rich interfaces and flexible deployment capabilities
    Dual Gigabit cards such as USB, HDMI, RS-485, RS232, RJ45, self-righteous I/O, and MINI PCIE support dual network IP Settings, internal and external network isolation and other applications, suitable for various networking environments.
  • 04
    Supports multiple wireless transmissions
    Supports various wireless transmissions such as GPS, Wi-Fi, 4G/5G LTE, Lora, etc.
  • 05
    Support hard disk expansion
    Supports M.2 NVMe SSD hard disk expansion.
  • 06
    Industrial-grade products, stable and reliable
    Condensing silicone grease has excellent heat dissipation performance, is resistant to surges and lightning strikes, and supports wide-temperature working environments.
Application Scenarios
  • Smart Vehicle
    Mobile patrol law enforcement
  • Food Safety
    Open kitchens and transparent stoves, etc
  • Work Safety
    Smart construction sites, chemical plants, storage and gas stations, fire emergency response, etc
  • Intelligent Inspection
    Power inspection, unmanned operation, etc
  • New Retail
    Business halls, supermarkets, chain stores, etc
Product Specifications
Product specification AI Edge Computing Power Box
TS-RK-F200 (4GB/8GB)
Operating system SoC RockChip RK3588
CPU RK3588, 4-core Cortex-A76, 4-core Cortex-A55, 2.6GHz
GPU Mali G610 Mc4
Memory DDR4 4GB/8GB
eMMC 32GB eMMC 5.1/64 GB eMMC 5.1
OS Ubuntu Linux/Debian/Android
Computing Power Computing Power 6Tops(INT8)
Video Coding 8K30fps H.264 和 H.265
Decoding 32*1080P, 8K@60fps H.265 and VP9、8K@30fps H.264, 4K@60fps AV1
HDMI 1 x HDMI 2.0
LAN RJ45 2*,100M/1000M
USB USB 2USB3.0; 1USB2.0
I/O (Phoenix Terminal Plug) RS485 1*, A or B
DI/DO 6-bit(3IN-3OUT)GPIO, 3*GND
RS232 1*, RXD and TX
Expand Expand M.2 nvme SSD (Upper 2TB) ; 1* NANO SIM,1* Micro SD;1* 4G/5G,1GPS,1Wi-Fi;
Audio Audio In/Out 3.5mm Earphone holder
Key Key Recovery1; Reset1
Power Conn DC 12 (Typical:DC12V 3A)
Indicator Power/run Power indicator light (blue light, constantly on: powered on; off: powered off; system operation indicator light RUN)
4G/HDD 4G signal indicator light (blue light, constantly on: stable signal; flashing: search signal; no light: no signal)
Size 195.6(L)*125.0(W)*53.5(H)mm;2kg
Environment Operational Temperature:-20℃--65℃;Storage Temperature:-40℃--80℃
